General specifications | |
Model No. | C11 |
Channel Space | 12.5kHz/25KHz |
Frequency Range | UHF:400-470MHz |
Dimension | 125mm*53mm*32mm |
Memory Channel | 16 |
Operating Voltage | 7.4V |
Battery capacity | 1200mAh |
Screen | 1.77 inch color screen |
Resolution | 128×160 pixel |
Operating temperature | -10℃~+55℃ |
Storage temperature | -40℃~+85℃ |
Receiver |
 Receiver Sensitivity | ≤0.18uV/0.22uV |
 Adjacent Channel Selectivity |  ≥60dB |
Blocking | ≥80dB |
ntermodulation | ≥60dB |
Spurious Rejection | ≥70dB |
SNR | ≥50dB |
RX Audio Power | 0.5W |
Audio Distortion | ≤5% |
Transmitting |
Modulation Mode | 16kΦF3E/8kΦF3E |
Modulation Limiting | ±5kHz/±2.5kHz |
Audio Distortion | ≤5% |
Residual frequency
modulation: |
-45dB |
Adjacent Channel Power | -67dB |
Spurious and harmonic | -36dBm<1GHz -30dBm>1GHz |
