| General specifications | |
| Model No. | C11+ |
| Channel Space | 12.5kHz/25KHz |
| Frequency Range | UHF:400-470MHz |
| Dimension | 125mm*53mm*32mm |
| Memory Channel | 16 |
| Operating Voltage | 7.4V |
| Battery capacity | 2500mAh |
| Screen | 1.77 inch color screen |
| Resolution | 128×160 pixel |
| Operating temperature | -10℃~+55℃ |
| Storage temperature | -40℃~+85℃ |
| Receiver |
|  Receiver Sensitivity | ≤0.18uV/0.22uV |
|  Adjacent Channel Selectivity |  ≥60dB |
| Blocking | ≥80dB |
| ntermodulation | ≥60dB |
| Spurious Rejection | ≥70dB |
| SNR | ≥50dB |
| RX Audio Power | 0.5W |
| Audio Distortion | ≤5% |
| Transmitting |
| Modulation Mode | 16kΦF3E/8kΦF3E |
| Modulation Limiting | ±5kHz/±2.5kHz |
| Audio Distortion | ≤5% |
| Residual frequency
modulation: |
-45dB |
| Adjacent Channel Power | -67dB |
| Spurious and harmonic | -36dBm<1GHz -30dBm>1GHz |
