- Output Power(w): 3w-5w
- Battery Capacity(mAh): High Capacity
- Waterproof / Water-Resistant: IP45
- Material: Plastic
- Storage Channel: 1024
- Frequency Range: VHF 136-174MHz / UHF400-470MHz
- Dimensions: 136*62*36mm(Antenna Not include
- Model Number: DR-1801
- Walkie Talkie Type: Portable
- Is_Display: Yes
- Maximum Range: 5km-10km
- Brand Name: BAOFENG
- Origin: Mainland China
Specifications:
General | |
Frequency Range | VHF:136-174MHz, UHF:400-470MHz (Dual Band) |
Memory Channel | 1024 |
Operating Voltage | DC 7.4V |
Frequency stability | ±1.0ppm |
Demission | 133*62*32mm (no including the antenna) |
Operating environment | -30℃-+60℃ |
Weight | Approach.274g(including the battery and antenna) |
Transmitter | |
Output power | High:5W Low:1W |
Adjacent channel power | ≤65dB ≤60dB |
Output consumption | Analog≤1.6A Digital≤0.9A |
Audio response | +1~3dB |
Standby current consumption | ≤0.18A |
Digital Protocol | ETSI-TS102 361-1,-2,-3 |
Modulation distortion | ≤5% |
Vocoder type | AMBE+2 TM |
FM/FM modulation: | 16K¢F3E,25KHz 141K¢F3E,20KHz 11K¢F3E,12.5KHz |
4FSK/4FSK digital modulation | 12.5KHz for data:7K60FXD 12.5KHz for data and voice:7K60FXE |
Signal-to-noise(wide/narrow) | ≥45dB,25KHz ≥40dB,12.5KHz |
Antenna Port Spurious | 9KHz-1GHz ≤-36dBm 1GHz-12.75GHz: ≤-30dBm |
Receiver | |
Analog receive sensitivity | -122dBm (12dB SINAD) |
Digital receive sensitivity | -122dBm (BER≤5%) |
Audio power | 1W |
Audio distortion | <10% |
Signal imitation | ≥70dB |
Audio response | +1~3dB |
Receive current | ≤380mA |
Intermediation(wide/narrow) | ≥62dB/≥58dB |
Adjacent channel selectivity | ≥65dB/≥60dB |
PM noise | ≥45dB,25KHz / ≥40dB,12.5KHz |
Package Contain:
1× BAOFENG DR-1801
1× Li-ion Battery Pack
1× Charger Unit with AC Adapter
1× Antenna
1× Hand Strap
1× Belt Clip
1× Earpiece
1× User Manual
(And other accessory depend on your choice in the link)
